5Nm-18Nm 24VDC Multi Turn Actuator 1-7 Turns Adjustable

​Features:

• 1-7r adjustable per valve stroke with double side torque limit protection
• DC brushless motor with rare earth material permanent magnet and current overload protection
• Torque closes valve and highly sealed in close position torque from 5Nm to 18Nm adjustable
• Rugged IP67 and type 4X with aluminum alloy enclosure
• Super mini volume smaller size than a cola can
• Manual override with Allen handle
• Two LED lights to confirm full open and close position of valve
• CE marked/RoHS 3.0 declared

Product specification

Multi-turn 24VDC Electric actuator is a new type actuator developed by DCL.

Technique Parameters:
1. Electric level, pulse control signal
2. Full-open , Full close postion output signal.
3. Voltage: DC24V±15%
4. Current: 1.1A
5. Output torque: 18Nm
6. Temperature: -25~75℃
7. Enviroment Humidity:≤95%RH

Description

DCL-MZZ electric actuators can be used to motorize PVC diaphragm valves. PVC diaphragm valves are typically used for on-off control of abrasive or liquids with suspended solids and other media compatible with the materials of construction. Linear sealing motion provides linear flow control characteristics. Thus inching mode of actuator can be used to precisely control flow.

The double direction over torque protection function can prevent actuator over screwed the PVC valve. The over-torque shut off valve can make sure the valve sealing very well and open smoothly.

Founded in 2001, Dynamic Corporation Limited(DCL) is a national high-tech enterprise, which is engaged in R&D, manufacturing and sale of Electric Actuator, Electric Valve and its Automation Control System. The main leading product, DCL Series Electric Actuator is featuring the compact construction, exquisite appearance, smart control, remarkable performance,easy operation and so on.

DCL series electric actuators are widely used in various industrial field, such as HVAC, refrigeration, petroleum, chemical, electric power, smelting, energy, pharmaceutical, paper-making, water treatment, food, brewage, shipbuilding and combustion system etc. DCL has estabilished stable partnership with lots of world leading companies in each industry to provide best flow control solutions. Every year, DCL also exports over 10000 units self-produced electric actuators and electric valves to USA and Germany.

In the past 19 years, DCL has winned high trust-worthy from customers. Many customers with many years practices confirm that our products are outstanding in stable quality, reliability, durability and after-sale service.

1. Manufacture per ISO9001:2015 standard with certification

2. Products are CE marked/ATEX marked with QAN by SGS group

3. Products are certificated per UL and CSA standard by CSA group

DCL does not only provide good quality products, but also present responsibility to the society and community. All our employees regard quality first. Quality control has a long uninterrupted way to go. Quality first is our management culture and the foundation of our company.
